Holley LS Swap Oil Pan Retrofit – LS1, 5.3L, 6.0L, LQ, LSX for Camaro & Nova Applications

Description

Engine Oil Pan, Retrofit, Rear Sump, 5-1/2 qt, 5-29/32 in Deep, Tray / Pickup Included, Aluminum, GM LS-SeriesFeatures:

• Provides OEM fitment: OEM filter mounting, oil cooler port provision, engine NVH suppression, flange gasket and sealing, and OEM bellhousing attachments
• Cast and machined aluminum construction with proper structural rigidity
• Traditional high-quality cast aluminum appearance with clean exterior styling
• Provides maximum clearance to chassis
• Complete kit includes sump baffle, pick-up tube, sump plug, and oil passage cover
• Fits GM rear wheel drive applications originally equipped with small or big block engines and a tradition rear sump oil pan*
• Maximum crankshaft stroke – 4.25″
• Sump oil capacity – 5.5 quarts
• Total oil capacity with stock oil filter – 6 quarts
• Oil filter: AC Delco PF48/PF48E, Mobil M1-113, Wix 57060, K&N HP-1017, or equivalent

** Requires the use of LS3 dipstick (GM part #12669528) and tube (GM part #12625031)
